Leírás
| Throughput Speeds (landscape orientation) |
PS80: up to 85 pictures (4 x 6-inch size) per minute at 300 dpi PS50: up to 50 pictures (4 x 6-inch size) per minute at 300 dpi (Throughput speed may vary depending on your choice of operating system, PC and print size) |
| Bundled Software | KODAK Picture Saver Scanning Software; Smart Touch functionality for "one button" document scanning; TWAIN driver (applies to running on Windows based PC's only) |
| Photo Image Enhancement | Selectable Image Cleaner Tool to optimize captured image quality by reducing the effects that environmental factors, like dust, may cause; red-eye removal; KODAK PERFECT TOUCH Technology customized for photo scanning (photo retouching, contrast adjustment and color correction - applies to running on Windows based PC's only); auto deskew; auto cropping; image rotation (manual and automatic); image sharpening (during scanning with the PS80, post-scan with the PS50 - applies to running on Windows based PC's only) |
| Optional Accessories | KODAK A3 and Legal Size Flatbed Accessories to handle oversize and fragile pictures and documents, including scrapbook pages (applies to running on Windows based PC's only); Document Separation Module; KODAK Gentle Photo Separation Module, KODAK Photo Selector Accessory |
| Optical Resolution | 600 DPI |
| Illumination | Dual indirect LED |
| Output Resolution | 300, 600 and 1200 (1200 is interpolated) dpi |
| File Format Output | Picture scanning: single-page JPEG (PS50 and PS80); TIFF (PS80) Document scanning: single and multi-page TIFF, JPEG, RTF, BMP, PDF, searchable PDF |
| Supported Output Media | Portable USB drives, DVD, CD, KODAK Picture CD |
| Maximum Photo Size | Scanner: 216 mm x 863 mm (8.5 in. x 34 in.) Scanner with A3 Flatbed: 302 mm x 461 mm (11.9 in. x 18.2 in.) Scanner with Legal Size Flatbed: 216 mm x 356 mm (8.5 in. x 14.0 in.) |
| Minimum Photo Size | 50 mm x 63.5 mm (2 in. x 2.5 in.) |
| Scanning Technology | Dual CCD; Grayscale output bit depth is 256 levels (8-bit); color capture bit depth is 48 bits (16 x 3); color output bit depth is 24 bits (8 x 3) |
| Picture Feeding | Continuous feeding of pictures is supported PS80: up to 50 mixed-size pictures per batch PS50: up to 25 mixed-size pictures per batch |
| Document Feeding | Document feeder capacity of up to 50 sheets (PS50) or 75 sheets (PS80), handling paper weights up to 34-413 g/m² (9-110 lb.); ID card thickness: up to 1.25 mm (0.05 in.) |
| Connectivity | USB 2.0, USB 3.0 compatible |
| Document Imaging Features | Perfect Page Scanning (iThresholding; adaptive threshold processing; deskew; autocrop; relative cropping; aggressive cropping; electronic color dropout; dual-stream scanning; interactive color, brightness and contrast adjustment; auto orientation, automatic color detection, background color smoothing); Smart Touch functionality (applies to running on Windows based PC's only) |
| Electrical Requirements | 100–240V (international); 50–60 Hz |
| Electrical Rating | 24V dc 1.875A |
| Power Consumption | Scanner: off mode: <0.35 watts; sleep mode: <4 watts; running mode: <32 watts |
| Environmental Factors | Operating temperature: 10-35° C (50-95° F); Operating humidity: 15% to 76% RH |
| Recommended PC Configuration | For photos and documents up to 660 mm (26 in.) long at 400 dpi: INTEL CORE2, 2.1 GHz Duo Processor or equivalent, 2 GB RAM For longer documents / higher resolutions: INTEL CORE2, 2.1 GHz Duo Processor or equivalent, 4 GB RAM Note: for optimal performance when using a PC running the WINDOWS 7 operating system, at least 3 GB RAM is recommended |
| Supported Operating Systems | WINDOWS XP SP3 (32-bit) WINDOWS XP x64 Edition SP2 WINDOWS VISTA SP2(32-bit and 64-bit) WINDOWS 7 SP1 (32-bit and 64-bit) WINDOWS 8 (32-bit and 64-bit) MAC OS V10.6 - 10.10 and greater (applies to driver only, user must supply own scanning application such as ADOBE Photoshop or ADOBE Elements) |
| Approvals and Product Certifications | AS/NZS CISPR 22:2006 Class B (RCM ), CAN/CSA-C22.2 No. 60950-1-07 (C-UL Mark), Canada ICES-003 Issue 4 (Class B), GB4943, GB9254 (Class B), GB 17625.1 Harmonics (CCC "S&E" Mark), EN 55022 ITE Emissions (Class B), EN 61000-3-3 Flicker, EN 55024 ITE Immunity (CE Mark), EN 60950-1:2006 2nd ed. CE Mark, IEC 60950-1:2005 2nd ed., CISPR 22 (Class B), UL 60950: 1-07 (UL Mark), CFR 47 Part 15 Subpart B (FCC Class B), Argentina S-Mark, Russia GOST |
| Consumables Available | Feed Rollers, Roller Cleaning Pads, BRILLIANIZE Detailer Wipes for KODAK Scanners, Transport Cleaning Sheets |
| Dimensions | Weight: 5.5 kg (12 lbs.) Depth: 162 mm (6.3 in.) not including input tray and output tray Width: 330 mm (13 in.) Height: 246 mm (9.7 in.) not including input tray |
| Language Support | GUI available in 14 languages |
| Warranty (US and Canada) | One-year Advanced Unit Replacement (AUR); Option for two- or three-year extended warranty |
| What's in the Box | Picture Scanner; Picture Saver Scanning Software; Smart Touch application for document scanning; Instructions for installation, setup and operation; USB Software dongle; International power cords; Power supply; Starter pack of cleaning supplies (BRILLIANIZE Detailer Wipes for KODAK Scanners, Roller Cleaning Pads, Transport Cleaning Sheets); Dust cover; Pre-separation pad (optional for document scanning); Document Separation Module (for use when scanning documents rather than photos) |
Specifications are subject to change without notice.
