Előnyök
-
Straight paper path and Paper Picking Control function to ensure stable paper feeding
-
Manual Feed Mode for handling various thicknesses and sizes
-
Paper Protection function and Skew Reducer to protect important documents
-
Back-lit LCD panel for easy operation
-
Independent Side Guides for easily aligning mixed size documents
-
Comes with PaperStream IP and PaperStream Capture providing advanced image processing functions
-
PaperStream Capture Pro available as an option
Paraméterek
| Scanner Type | ADF (Automatic Document Feeder) / Manual Feed, Duplex |
| Scanning Speed (A4 Landscape) | Simplex:100 ppm, Duplex:200 ipm (200 dpi / 300 dpi) |
| Scanning Speed (A4 Portrait) | Simplex:80 ppm, Duplex:160 ipm (200 dpi / 300 dpi) |
| Image Sensor Type | Color CCD x 2 (front x 1, back x 1) |
| Light Source | White LED Array x 4 (front x 2, back x 2) |
| Optical Resolution | 600 dpi |
| Output Resolution | 50 to 600 dpi (adjustable by 1 dpi increments), 1,200 dpi (driver) |
| Output Color Depth | Color:24-bit, Grayscale:8-bit, Monochrome:1-bit |
| Background Colors | White / Black (selectable) |
| Document Size (ADF) | Minimum:50.8 x 69 mm (Portrait); Maximum:304.8 x 431.8 mm; Long Document:5,588 mm |
| Document Size (Flatbed) | Maximum:304.8 x 457.2 mm |
| ADF Feeding Paper Weight (Thickness) | Paper:20 to 413 g/m²; Less than A8 size:128 to 209 g/m²; Plastic Card:Up to 1.4 mm |
| ADF Capacity | 300 Sheets (A4:80 g/m²) |
| Expected Daily Volume | 44,000 Sheets |
| Multifeed Detection | Overlap detection (Ultrasonic sensor), Length detection |
| Paper Protection | Lag detection, Sound detection (iSOP) |
| Interface | USB 3.1 Gen 1 / USB 2.0 / USB 1.1 (backward compatible) |
| Power Requirements | 100 to 240 VAC ±10 % |
| Power Consumption | Operating mode:64 W or less, Sleep mode:1.7 W or less, Auto Standby(Off) mode:0.35 W or less |
| Dimensions (WxDxH) | 236 x 432 x 214 mm |
| Weight | 11 kg |
| Environmental Compatibility | ENERGY STAR / RoHS |
| Operating Environment Temperature | 5 to 35°C |
| Relative Humidity | 20 % - 80 % (non-condensing) |
| Included Software / Drivers | PaperStream IP Driver (TWAIN/TWAIN x64/ISIS), WIA Driver, PaperStream Capture, ScanSnap Manager for fi Series, Software Operation Panel, Error Recovery Guide, ABBYY FineReader for ScanSnap™, Scanner Central Admin, 2D Barcode for PaperStream |
| Supported Operating System | Windows® 10, Windows® 8.1, Windows® 7, Windows Server® 2019, Windows Server® 2016, Windows Server® 2012 R2, Windows Server® 2012, Windows Server® 2008 R2, Windows Server® 2008 |
| Image Processing Function | Multi image output, Automatic color detection, Blank page detection, Dynamic threshold (iDTC), Advanced DTC, SDTC, Error diffusion, Dither, De-Screen, Emphasis, Dropout color (None/Red/Green/Blue/White/Saturation/Custom), sRGB output, Hole punch removal, Index tab cropping, Split image, De-Skew, Edge correction, Vertical streaks reduction, Cropping, Static threshold, Divide long page |
| Inbox Contents | Stacker, ADF paper chute, AC cable, AC adapter, USB cable, Setup DVD-ROM |
