Előnyök
-
Scan from the scanner with touch screen operation
-
Various authentication methods for improved efficiency and security
-
Scan from your smart device/thin client to any business platform
-
5 types of SDKs to suit any environment
-
PaperStream NX Manager and Scanner Central Admin for centralized management
-
Paper Protection function protects scans from jamming by detecting anomalies in document length and sound
-
Manual Feed Mode for scanning folded or bound documents
Paraméterek
| Scanner Type | ADF (Automatic Document Feeder), Duplex |
| Image Sensor Type | Color CCD x 2 (front x 1, back x 1) |
| Light Source | White LED Array x 2 (front x 1, back x 1) |
| Optical Resolution | 600 dpi |
| Output Resolution | 50 to 600 dpi (adjustable by 1 dpi increments), 1,200 dpi (driver) |
| Output Format | Color:24-bit, Grayscale:8-bit, Monochrome:1-bit |
| Background Colors | White / Black (selectable) |
| Scanning Speed (A4 Portrait) | Simplex:60 ppm (200/300 dpi), Duplex:120 ipm (200/300 dpi) |
| ADF Capacity | 80 Sheets (A4:80 g/m2) |
| Expected Daily Volume | 9,000 Sheets |
| Document Size | ADF Minimum:50.8 mm x 54 mm; ADF Maximum:216 mm x 355.6 mm ; Long Document:216 mm x 5,588 mm |
| Paper Weight (Thickness) | Paper:27 g/m2 to 413 g/m2; Card:Up to 1.4 mm |
| Interface | |
| USB | USB 3.1 Gen1 / USB 3.0 / USB 2.0 / USB 1.1 |
| Ethernet | 10BASE-T, 100BASE-TX, 1000BASE-T |
| Wi-Fi | IEEE802.11 a/b/g/n/ac; Frequency band:2.4 GHz / 5 GHz |
| Wi-Fi Interface | |
| Rated Power (EIRP) (North America) | 2.4 GHz:11b:+23.5dBm, 11g:+22.0dBm, 11n/ac:+22.0dBm (20/40MHz); 5 GHz:11a:+15.5dBm, 11n/ac:+16.5dBm (20MHz) |
| Rated Power (EIRP) (Others) | 2.4 GHz:11b:+19.0dBm, 11g:+20.5dBm, 11n/ac:+20.5dBm (20/40MHz); 5 GHz:11a:+15.5dBm, 11n/ac:+16.5dBm (20MHz) |
| Network Protocols | IPv4 (16), TCP, UDP, ICMP, DHCP, HTTP/HTTPS, DNS |
| Power Requirements | 100 to 240 VAC ±10 % |
| Power Consumption | Operating mode:42 W or less, Sleep mode:2.4 W or less, Power Off mode:0.35 W or less |
| Dimensions (WxDxH) | 300 x 202 x 170 mm |
| Weight | 4.9 kg |
| Environmental Compliance | ENERGY STAR®, RoHS |
| Operating Environment Temperature | 5 to 35°C |
| Relative Humidity | 20 % - 80 % (non-condensing) |
| Supported Operating System | Windows® 10, Windows® 8.1, Windows® 7, Windows Server® 2019, Windows Server® 2016, Windows Server® 2012 R2, Windows Server® 2012, Windows Server® 2008 R2, Windows Server® 2008 |
| Included Software / Drivers | PaperStream IP Driver (TWAIN/TWAIN x64/ISIS), WIA Driver , PaperStream Capture, ScanSnap Manager for fi Series, Software Operation Panel, Network Setup Tool, ABBYY FineReader for ScanSnap™, Scanner Central Admin |
| Inbox Contents | Chuter unit, AC cable, AC adapter, USB cable, Setup DVD-ROM |
Vélemények
Erről a termékről még nem érkezett vélemény.
Írja meg véleményét!
Leírás és Paraméterek
| Scanner Type | ADF (Automatic Document Feeder), Duplex |
| Image Sensor Type | Color CCD x 2 (front x 1, back x 1) |
| Light Source | White LED Array x 2 (front x 1, back x 1) |
| Optical Resolution | 600 dpi |
| Output Resolution | 50 to 600 dpi (adjustable by 1 dpi increments), 1,200 dpi (driver) |
| Output Format | Color:24-bit, Grayscale:8-bit, Monochrome:1-bit |
| Background Colors | White / Black (selectable) |
| Scanning Speed (A4 Portrait) | Simplex:60 ppm (200/300 dpi), Duplex:120 ipm (200/300 dpi) |
| ADF Capacity | 80 Sheets (A4:80 g/m2) |
| Expected Daily Volume | 9,000 Sheets |
| Document Size | ADF Minimum:50.8 mm x 54 mm; ADF Maximum:216 mm x 355.6 mm ; Long Document:216 mm x 5,588 mm |
| Paper Weight (Thickness) | Paper:27 g/m2 to 413 g/m2; Card:Up to 1.4 mm |
| Interface | |
| USB | USB 3.1 Gen1 / USB 3.0 / USB 2.0 / USB 1.1 |
| Ethernet | 10BASE-T, 100BASE-TX, 1000BASE-T |
| Wi-Fi | IEEE802.11 a/b/g/n/ac; Frequency band:2.4 GHz / 5 GHz |
| Wi-Fi Interface | |
| Rated Power (EIRP) (North America) | 2.4 GHz:11b:+23.5dBm, 11g:+22.0dBm, 11n/ac:+22.0dBm (20/40MHz); 5 GHz:11a:+15.5dBm, 11n/ac:+16.5dBm (20MHz) |
| Rated Power (EIRP) (Others) | 2.4 GHz:11b:+19.0dBm, 11g:+20.5dBm, 11n/ac:+20.5dBm (20/40MHz); 5 GHz:11a:+15.5dBm, 11n/ac:+16.5dBm (20MHz) |
| Network Protocols | IPv4 (16), TCP, UDP, ICMP, DHCP, HTTP/HTTPS, DNS |
| Power Requirements | 100 to 240 VAC ±10 % |
| Power Consumption | Operating mode:42 W or less, Sleep mode:2.4 W or less, Power Off mode:0.35 W or less |
| Dimensions (WxDxH) | 300 x 202 x 170 mm |
| Weight | 4.9 kg |
| Environmental Compliance | ENERGY STAR®, RoHS |
| Operating Environment Temperature | 5 to 35°C |
| Relative Humidity | 20 % - 80 % (non-condensing) |
| Supported Operating System | Windows® 10, Windows® 8.1, Windows® 7, Windows Server® 2019, Windows Server® 2016, Windows Server® 2012 R2, Windows Server® 2012, Windows Server® 2008 R2, Windows Server® 2008 |
| Included Software / Drivers | PaperStream IP Driver (TWAIN/TWAIN x64/ISIS), WIA Driver , PaperStream Capture, ScanSnap Manager for fi Series, Software Operation Panel, Network Setup Tool, ABBYY FineReader for ScanSnap™, Scanner Central Admin |
| Inbox Contents | Chuter unit, AC cable, AC adapter, USB cable, Setup DVD-ROM |
